SPECIFICATIONS

Available materials: Satin, belt, webbing, fabric tape, elastic band, etc

Core components: bearings

Cutting type: Hot knife, straight and corner cuts

Degree of automation: Automatic

High-concerned chemical: None

Material: Organic Material

Power: 500W

Recommend Age: 14+

Type of power: Electric heating

Weight (KG): 95

cutting blades: Hot blade and angle cutting

weight: 95 kg



Features:



1.Easy Operation,It can cut automaticlly once set up the cutting length and quantity.

2.Self protection Function,It will stop automaticlly if the materials run out during the operation.

3.High speed,it can cut 100-120pcs per minute(50mm length for example)

4.High Accuracy,the cutting length is accurate cwing to a stepping motor and imported driver.

5.Reset Function,clear the cut numbers and restart counting.

6.Angle cut,it can cut max 45^o angle edge.



Specification:

Available Tape Width:	5~100mm(straight cut)  /  5-55mm(angle cut)
Available Cutting Length:	20~999999mm
Tape Cutting Speed:	50~110Pcs/Min
Cutting Tolerance:	≤0.5mm
Cutting Type:	Hot knives,Straight cut & Angle cut
Knife Temperature	Max 350 degrees,Adjustable
Angle Cut:	0~45 degrees,Automatic adjustment
Available Cutting Shape:	Rectangular, parallelogram, trapezoid
Frequency:	50KHZ
Power Supply:	AC220V/110V
Air Pressure:	0.5kg/m2
Output Power Rated:	0.5KW
Available Materials:	Fabric,satin,webbing tapes,elastic tapes and belts, Tapes need heat sealing edge and etc.
Measurement:	750*600*1040mm
Weight:	95kg
